VEHICLE DETAILS | |
---|---|
MAKES: | Ford |
MODELS: | Expedition, F-150, F-250, F-350, F-450, F-550, F-Series, Flex, Fusion, E-350, E-450, E-Series |
YEARS: | 2010-2016 |
ENGINES: | 2.5L, 3.7L, 3.7L Ti-VCT, 5.0L, 5.4L, 6.2L, 6.8L |
MODULE: | Engine Module |
USAGE: | 2012-2014 Ford Expedition 5.4L 2011-2014 Ford F-150 3.7L 2011-2014 Ford F-150 5.0L 2010-2014 Ford F-150 6.2L 2011-2016 Ford F-250 6.2L 2011-2016 Ford F-350 6.2L 2011-2016 Ford F-450 6.2L 2011-2016 Ford F-550 6.2L 2012-2016 Ford F-250 6.8L 2012-2016 Ford F-350 6.8L 2012-2016 Ford F-450 6.8L 2012-2016 Ford F-550 6.8L 2013-2015 Ford Flex 3.5L Ti-VCT 2013-2016 Ford Fusion 2.5L 2013-2016 Ford Fusion 3.7L 2013-2015 Ford E-350 6.8L 2013-2015 Ford E-450 6.8L |
ALIASES: |
SUPPORTED COMMUNICATION PROTOCOL(S) | DLC PIN(S) |
---|---|
CAN BUS | 16 WAY OBD-II DLC PINS 6 & 14 |
POWERBLOCK CONNECTION
For communication on OBD-II DLC pins 6, 13, and 14, this harness requires Ford Pass-Through Harness to connect to PowerBlock. Ford Pass-Through Harness sold separately. |
